Bike Defect Notifier is a cloud-native microservices application for people who like to share defects in local bike infrastructure. Bike Defect Notifier consists of a 2-tier microservices application. The application is a web-based OpenAPI where users can report faults on public infrastructure.
With this application we would like to demonstrate the use of microservices in a cloud world without vendor lock-in. This application works on all Docker hosts, but can also be rolled out on standard Kubernetes clusters.
Please note that in this project there is no explicit protection of the target system in terms of cyber security. The protection of the work node on which the application is executed is the responsibility of the system operator.
If you’re using this application, please ★Star this repository to show your interest! Collaboration on this repo is expressly encouraged.
Before You Begin
To successfully deploy this microservice to your target system, please ensure that you have successfully completed the installation of Docker.
Install Docker
To install Docker Engine, follow the instructions within one of the guides below:
Install Docker Compose
In addition to the Docker Engine, Docker Compose must also be installed on the target system.
Quickstart (Docker)
- Clone this repository.
git clone https://git.masasana.ai/DamageDetector/DamageDetector.git
cd DamageDetector
- Deploy the app to your local cluster.
bash ./scripts/local_deploy.sh
- Wait for the stack to be ready.
docker stack ps DamageDetector
After a few minutes, you should see:
ID NAME IMAGE NODE DESIRED STATE CURRENT STATE ERROR PORTS
xy5n7qwqrhp6 DamageDetector_mongo.1 mongo:5.0 .3 localhost Running Running 1 minute ago
x8inapxrfsc7 DamageDetector_frontend.1 frontend:latest localhost Running Running 1 minute ago
- Access the web frontend in a browser using the frontend's
EXTERNAL_IP.
http://localhost:8080/ui
Other Deployment Options
- Istio: See these instructions.
- Minikube: see the Development Guide
Architecture
DamageDetector is composed of 2 microservices written in different languages that talk to each other.
The cloud architecture shown here represents an exemplary network infrastructure that can be adapted by the operator as desired. It makes no claim to completeness or correctness.
| Service | Language | Description |
|---|---|---|
| frontend | Python | Exposes an HTTP server to serve the website. Does require basicAuth signup/login to interact with the API |
| mongodb | C++ | Stores demage notifications from user's. |
Features
- CNCF - Cloud Nativ Computing Foundation: This application is developed according to the recommendations of the CNCF.
- Kubernetes/Docker: The app is designed to run on Kubernetes (both locally on "Docker for Desktop", as well as on the cloud).
- Istio: Application works on Istio service mesh.
Local Development
If you would like to contribute features or fixes to this app, see the Development Guide on how to build this demo locally.
